Scotch-Weld 2216
Structural Epoxy
Kwik-Gard
TM
Part No.
Description
Curing time
Useful Applications and Characteristics
Epoxies
Form strong bonding. Used in wire bonding applications.
4898
Silver filled conductive Epoxy
12 hrs@50C; 5 min @150C
Connecting conductors that can't be soldered. Constructing or connecting Ag/AgCl pellets.
7335
Carbon filled conductive Epoxy
48 hrs@25C; 5 min @150C
Constructing carbon electrode.
4886
High performance Structural Epoxy
12 hrs@25C.
Forms a strong and slightly flexible bond on plastic, metal, and glass. Bonds some low surface .
Hot melt (EVA)
Easy to use for bonding, needs large gap filling
13316
Mini Glue Gun with glue sticks
As soon as it cools down
Bonds wood, glass, metals, and many plastics.
Silicone Adhesives/Sealants/Primers
Good moisture resistant and elastic. Low toxic.
1571
Room temperature vulcanizing (RTV)
adhesive. Acyloxy/moisture cure system.
Acetic acid is cure by-product.
24hrs@25C
Has the best adhesion property in this silicone family. Will bond to many materials.
7128
RTV sealant. Alkoxy/Moisture cure
system. Methanol as cure by-product.
72hrs@25C
Good for bonding or sealing electronics circuits (metal).
SYLG184
Sylgard, Two parts, vinyl/platinum cure
sealant. Hydrogen as cure by-products.
Very low toxic
24hrs@25C, 15 min.@150C
Coating Patch Clamp electrodes, Cell culture dish, making dissection pads.
Kwik-Sil
Two part, adhesive. Vinyl/platinum
system, Hydrogen as cure by-products.
Very low toxic.
< 5 min@25C
Live tissue and nerve studies. Medium strength adhesion.
Kwik-Cast
Two part sealant. Vinyl/platinum cure
system. Hydrogen as cure by-products.
Very low toxic.
< 5 min@25C
Sealant for live tissues. Embedding peripheral nerves with electrodes.
6820
Primer for silicone
N/A
Enhances adhesion of silicone adhesives for difficult to bond plastic surfaces
Cyanoacrylate
Forms an instantaneous bonding.
7341
Ethyl Cyanoacrylate, low viscosity
90-120 cps
<10 seconds
Mounting rat/mouse brain slices. Ideal for relatively small gaps and smooth surfaces.Bonds plastic, metals
and rubber. Package of 10 vials, each approximately 1.5 mL.
7342
Ethyl Cyanoacrylate, high viscosity
1100-1600 cps
<30 seconds
Use on brain slice exp. Ideal for larger gaps, allows slightly longer bonding time. Bonds plastic, metals and
rubber. Package of 10 vials, each approximately 1.5 mL.
Vetbond
Butyl Cyanoacrylate, Low toxic
<10 seconds
Bonds tissues, alternative to suture, helps small wound healing. Antimicrobial effect. Used in forensic
science.
503763
Octyl Cyanoacrylate, Low toxic
<15 seconds
Suitable for surface wound bonding, protection, holding a sensor or other device on the tissue.
Kwik-Gard is specially packaged
Sylgard 184 silicone for quicker
and easier application, eliminating
the messy procedure of preparing
the mixture before application. Its
special cartridge controls the precise
mixing ratio to ensure proper curing.
The disposable tip mixes resin and
hardener as they are dispensed. Since no air is
introduced during mixing, the resin does not need
degassing for most applications. The mixed silicone
is applied directly to the site, reducing preparation
time and material waste.
Each Kwik-Gard cartridge contains 37 mL of
resin and hardener. The dispensing tip has a dead
volume of 0.75 mL.
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
World Precision Instruments
www.wpiinc.com
UK: Tel: +44 (0)1462 424700 · wpiuk@wpi-europe.com Germany: Tel: +49 (0)30-6188845 · wpide@wpi-europe.com US: Tel: 941-371-1003 · sales@wpiinc.com
KWIKGARD Kwik-Gard Start-up Kit
(incl. dispenser, 1 cartridge, 5 tips)
KWIKGLUE
Kwik-Gard Refill (2 cartridges,
10 dispensing tips)
KWIKMIX
Dispensing Tips (pkg of 10)
KWIKGUN
Kwik-Gard Dispenser
Probably still the best epoxy for bonding plastic,
often used as the benchmark for testing the
binding strength of other adhesives. The slightly
rubbery texture also makes it less easy to break
off. It is the only epoxy known that can bond PEEK.
Color: gray. Cures at room tem per a ture.
Shipping weight: 1 lb. (0.5 kg)
4886
Scotch-Weld 2216 (2 oz.)
