PZMIII LED Ringlight PZMIII-BS #502007 Articulated Arm See Page 145 #502006 Boom Clamp Stand — Combines the stability of a boom stand with the versatility of an articulated arm. #502163 WallMount Plate — Mount the microscope on the wall for convenient storage when space is tight. Max. clamp opening: 50 cm MICROSCOPES, CAMERAS PZMIII Eyepieces and Objectives 10× Eyepiece Objective 0.3× 0.5× 0.75× 1.0× 1.5× 2.0× 15× Eyepiece Mag. 3× - 20.3× 5× - 33.8× 7.5× - 50.6× 10× - 67.5× 15× - 101.3× 20.1× - 135× 20× Eyepiece Mag. 4× -27× 6.7× - 45× 10× - 67.5× 13.4× - 90× 20.1×-135× 26.8×-180× 25× Eyepiece Mag. 5× - 33.8× 8.4× - 56.3× 12.6× - 84.4× 16.8×-112.5× 25.1×-168.8× 33.5× - 225× Mag. 2× - 13.5× 3.4× - 22.5× 5× - 33.8× 6.7× - 45× 10× - 67.5× 13.4× - 90× Field (mm) (Video Field)* 114 - 17 (53.6 - 8) 69 - 10 (32.4 - 4.7) 45 - 7 (21.1 - 3.3) 34 - 5 (16 - 4.7) 23 - 3.4 (10.8 - 1.6) 12 - 2.5 (5.6 - 1.17) Field (mm) (Video Field)* 84 -13 (53.6 - 8) 51 - 7 (32.4 - 4.7) 34 - 5 (21.1 - 3.3) 25 - 3.7 (16 - 4.7) 17 - 2.5 (10.8 - 1.6) 13 - 1.8 (5.6 - 1.17) Field (mm) (Video Field)* 69 - 10.3 (53.6 - 8) 42 - 6.2 (32.4 - 4.7) 28 - 4.2 (21.1 - 3.3) 21 - 3.1 (16 - 4.7) 14 - 2.1 (10.8 - 1.6) 10 - 1.5 (5.6 - 1.17) Field (mm) Working (Video Field)* Distance (mm) 44.8 - 6.7 (53.6 - 8) 26.9 - 4.0 (32.4 - 4.7) 17.9 - 2.7 (21.1 - 3.3) 13.4 - 2.0 (16 - 4.7) 9.0 - 1.3 (10.8 - 1.6) 6.7 - 1.0 (5.6 - 1.17) 287 mm 177 mm 117 mm 100 mm 47 mm 26 mm * The video field of view is based on a 1/2-inch (8 mm diagonal) CCD camera and a 0.5× camera adapter. OPTIONAL ACCESSORIES 501352 PZMIII Binocular Body, pair of 10x eyepieces and eyeguards 13338 Ring Light Adapter NOT included 501353 Fan Post Stand with 76mm Focus Mount 502009 Universal Focus Mount, 76 mm ID for PZMIII Body 502004 Boom Stand (Heavy) without Focus Mount 502005 Ball Bearing Boom Stand (Heavy) without Focus Mount 504123 Post Extension for Heavy Boom Stand 502006 Boom Clamp Stand (Heavy) (requires 502009 Focus Mount for PZMIV) 502007 Articulated Arm with Table Clamp, without Focus Mount (50 cm clamp) 502163 Wall-Mount Plate, 6" × 6" (or 15.24 cm × 15.24 cm) 501369 Wide Field 10× Eyepieces (pair) 501370 Wide Field 15× Eyepieces (pair) 501371 Wide Field 20× Eyepieces (pair) 501372 Wide Field 25× Eyepieces (pair) 504128 10× Eyepiece with Reticle (matches 10× eyepiece on PZMIII) 504129 20× Eyepiece with Reticle (matches 20× eyepiece 501371) 501373 0.3× Long Working Distance Objective Lens 501375 0.5× Long Working Distance Objective Lens 501376 0.75× Long Working Distance Objective Lens 501377 1.5× Long Working Distance Objective Lens 501378 2.0× Long Working Distance Objective Lens 501379 PZMTIII Trinocular Body, pair of 10× eyepieces and eye guards 13338 Ring Light Adapter NOT included 501381 0.5× C-Mount CCD Camera Coupler 13338 Ring Light Adapter for PZMIII Series (included with all microscope configurations on previous page) 503051 Manual Stage for PZMIII 503102 76mm Rectangular Base Post Stand for PZMIII UK: Tel: +44 (0)1462 424700 • wpiuk@wpi-europe.com #503051 Manual Stage — Mounts in the circular opening in the PZMIII base. XY travel distance: 75 x 56 mm. Glass size: 116 x 96 mm. Active diameter: 37.6 mm. Dimensions: 180 x 155 x 27 mm. Fits 503102 base only. PZMIII SPECIFICATIONS EYEPIECES ZOOM RANGE TOTAL MAGNIFICATION FIELD OF VIEW WORKING DISTANCE BINOCULAR TUBE INTERPUPILLARY DISTANCE DIOPTER ADJUSTMENT MICROSCOPE BODY AUXILIARY LENSES Total magnification Biggest Field of View Working Distance SHIPPING WEIGHT WFH 10× 0.67× - 4 .5× 6 .77× - 45× ∅ 34 MM - ∅ 5 MM 100 mm Inclined 45° Adjustable 47-70 mm ±5 Diopter (both eyepiece tubes) Rotatable 360° 2× - 225× ∅ 110 mm 26-287 mm 23 lb. World Precision Instruments www.wpiinc.com Germany: Tel: +49 (0)30-6188845 • wpide@wpi-europe.com US: Tel: 941-371-1003 • sales@wpiinc.com 143
